Nanni Diesel Marine engines: workshop manual and wiring diagrams

Download
Nanni Diesel Moteur 2.60HE Standard SPARE PARTS CATALOGUE
Nanni Diesel Moteur 2.60HE Standard SPARE PARTS CATALOGUE
Nanni Diesel Moteur 2.60HE Standard SPAR
Adobe Acrobat Document 1.5 MB
Download
Nanni Marine Diesel Engine N5.200 CR2, N5.230 CR2, N5.180 CR2, N5.150 Operator's Manual
Nanni Marine Diesel Engine N5.200 CR2, N5.230 CR2, N5.180 CR2, N5.150 Operator's Manual
Nanni Marine Diesel Engine N5.200 CR2, N
Adobe Acrobat Document 1.8 MB

Download
Nanni Marine Diesel Engine T4.155, 4.390 tdi, 4.380 td Workshop Manual
Nanni Marine Diesel Engine T4.155, 4.390 tdi, 4.380 td Workshop Manual
Nanni Marine Diesel Engine T4.155, 4.390
Adobe Acrobat Document 20.9 MB
Download
Nanni Marine Diesel Engine 4.200HE, 4.220HE, 4.195HE, D1503-M, D1703-M, D1803-M, V2203-M, V2403-M Workshop Manual
Nanni Marine Diesel Engine 4.200HE, 4.220HE, 4.195HE, D1503-M, D1703-M, D1803-M, V2203-M, V2403-M Workshop Manual
Nanni Marine Diesel Engine 4.200HE, 4.22
Adobe Acrobat Document 1.3 MB

NANNIDIESEL

The NANNIDIESEL company was founded in 1982 in France in the city of La Teste (Bordeaux). The company started out with the production of marine diesel engines based on Kubota. Today the company also produces marine diesel engines based on Kubota as well as MAN and Toyota engines. NanniDiesel's production facilities are certified and comply with the international standard ISO 9002, and the entire range of marine diesel engines and generators comply with the European requirements of the directives CEM 89/336 / CEE, 92/31 / EEC and 93/68 / EEC.



Marine diesel engine Nanni N13.660 CR 2

Nanni N13.660 CR 2 is a marine diesel belonging to the N13 silver engine series, developed on the basis of John Deere. This marine diesel has one of the highest horsepower (659 hp) in the entire Nanni range. The design of the marine diesel engine is thought out in such a way that all systems contribute to the maximum disclosure of the inherent horsepower. Thus, electronically controlled injectors produce a portioned and precise supply of fuel for better heating of the mixture. The air is discharged by a turbocharger equipped with an air intercooler. And the lubrication and cooling systems prevent friction and overheating of the main elements of the complex, respectively. The range of applications for the Nanni N13.660 CR 2 marine engine is extensive: rescue boats, fishing, diving and planing speed boats, as well as many other vessels.



Marine diesel engine Nanni 6.420TDI

The Nanni 6.420TDI marine diesel has inherited all the advantages of the original model - the Toyota engine for the all-wheel drive Land Cruiser. The model belongs to six-cylinder engines, with four valves per cylinder. The power of the marine engine is the best in its class with 320 horsepower. The engine displacement, like all representatives of the T6 series, is 4.16 liters. Due to the compliance of the marine diesel engine with the requirements of the SOLAS convention, it can be used in lifeboats and rescue boats. Well thought out systems of lubrication, cooling and fuel supply ensure the synchronous operation of the diesel engine. Most often, the Nanni 6.420TDI marine diesel engine is installed on pleasure craft.



Marine diesel engine Nanni N4.100

Marine diesel engine Nanni N4.100 - 4-cylinder engine with a volume of 3 liters. The model is widely used on RIBs, displacement vessels and pleasure craft (boats). The E-CDIS mechanical fuel system provides increased power, which in turn results in more torque. The rating assigned to this diesel engine - M4 - means that the full load on the equipment should not exceed 1 hour out of every 12 hours of operation. One of the main advantages of a marine engine is simple and inexpensive installation, as well as quite simple routine maintenance. Compliance with the SOLAS standard confirms the increased safety of using a marine diesel engine. That is why this marine diesel engine is often installed on boats that have to be dropped from a height of up to 30 meters (when organizing rescue operations on ships), or on ships operating in extremely low temperatures.

Comments: 2
  • #2

    Mr Maurice B Kuter (Monday, 27 May 2024 10:47)

    I am interested in purchasing the Nanni wiring diagram for our Nani N4: 100 Marine Diesel Engine.
    Can you please advise just what exactly to order to obtain this, please?

  • #1

    David Casha (Sunday, 03 April 2022 17:09)

    hi from were I can find work shop manual for nanni z6 300 bravo drive
    thanks
