Crestliner Boat Owners Manual PDF

Download
Crestliner Pontoon Owner's Manual
Crestliner Pontoon Owner's Manual
Crestliner Pontoon Owner's Manual_compre
Adobe Acrobat Document 9.3 MB
Download
Crestliner Boat Owners Manual
Crestliner Boat Owners Manual
Crestliner Boat Owners Manual_compressed
Adobe Acrobat Document 11.7 MB

CRESTLINER - ALL-WELDED ALUMINUM BOATS AND BOATS FOR FISHING AND SPORT

 Since 1946, Crestliner has proudly established itself as a manufacturer of boats that are simply built right and built to last. With superior design, excellent seakeeping, attention to detail and unrivaled value, the Crestliner name has become synonymous with the best aluminum boats in the world - the right boats!

The Crestliner 1850 Raptor WT is one of the best fishing boats out there. The boat is wide and stable in the parking lot, and this allows you to calmly approach the side without fear of capsizing. The powerful engine allows you to quickly get to the fishing spot - without wasting a lot of time. The boat has 4 adjustable seats, 3 aerators, two long lockers for spinning rods, an ice compartment, lockers, luggage nets and tackle organizers. If you are professionally fond of fishing, then this boat is made for you.

In 2012, the Crestliner Raptor line introduces models with new E-consoles with the ability to mount a large number of electronics, with a Blackbox stereo system, a backlit floor compartment, with a capacity of up to 10 rods. The new hull design has increased the cockpit space by 30 cm. Also, this year, a new model of the series - 2050 Raptor - was presented. The maximum allowable engine power for this boat is 300 hp.



Length, m.5.70

Width, m.2.45

Hull draft, m 0.50

Cockpit depth, m 0.69

Weight, kg. 667

Carrying capacity, kg. 737

Passenger capacity, pers. 7

Maximum engine power, h.p. 175

Fuel tank capacity, l. 125

Aluminum thickness: bottom, mm. 2.54

Aluminum thickness: board, mm. 2.28

Aluminum thickness: transom, mm. 3.17

Transom height, m 0.64

Kilnage at transom 17 °



Equipment



Cabin (Captain's place)



12 volt socket

Emergency stop switch

Deck console with wood-look inserts

Buzzer (Built-in)

Voltage (ground) switch.

Steering wheel with mechanical amplifier

Anti-glare panels

Wide windscreen (SC model only)

Stainless steel handlebars with handlebar tilt and seat adjustment

WT-Model with windshield with center passage to the bow includes SC3 left and right consoles with glove compartment.

Floor cover and seats



Waterproof carpet

3 Pro fishing chairs and 6 landing nests

Design / Quality / Safety



Highly resistant paint coating

Bilge pump (automatic)

Profile sideboards with rubber pads

Fire extinguisher

Dive level indicator

Nasal navigation lights

Handrails

Impregnated floor panel, for life. a guarantee

17º hull deadrise

Lockers / Beds / Accessories



Compartment for an additional (spare) battery

Live bait cage on the transom

Live bait cage with tray

Luggage nets along the side and in the bow

Chrome plated door latches

Lantern lighting on the cockpit

Storage compartment in the floor

"Crest-Liner" protective coating

Retractable stainless steel mooring cleats (4)

Protective Dock-Gard side moldings

Cup holders (3)

Locker on the bow, closable (nose) (1)

Locker on the bow with a removable tray (bow) (2)

Locker on the bow, lockable (right)

Drainage holes in the floor

91L aerated aquarium (nose)

Recirculated aquarium 110L. with timer, pump for pumping water (feed)

Compartment for placing fishing rods in the form of tubes (5pcs), top and open bottom (2.1m)

Rod compartment (2.4 m left)

Battery compartment (feed)

Transom fittings

12 / 24V trolling motor socket with off trim. (nose)

NEW - Lockable drawer under the console (front and right)

Comments: 2
  • #2

    Jane Phillips (Monday, 13 May 2024 18:12)

    I was just gifted a 1966 17' aluminum Crestliner. I would love to find a pdf of a user manual and/or a catalog. I would love to restore this boat and use it, but I need help with finding what the original looked like and how to source parts. Any advice/information would be much appreciated.
    creativejane@aol.com

  • #1

    Jeffry J Temple (Tuesday, 31 October 2023 20:48)

    my crestliner is older - replacing some of the floor pieces but what i am looking for is a floor plan of it ; from the front there are two centre hinged compartments with a seat hole between them for a pedastal - then a livewell in the centre which opens hinged and a piece that goes under the right side console -open area with two seat holes and one towards the back for another pedastal then raisedarea with battery compartment on non drivers side
    can u locate a couple of floor plans and send them along please
    thnx Jeff
